AdBlue Crystallisation: Symptoms, Causes, and How It Leads to Faults
Seeing white crust around the filler, under the van, or near the exhaust?
That can be AdBlue crystallisation. This guide shows what it looks like, why it happens, and when it turns into warnings and countdowns.
Mobile across Stoke-on-Trent, Staffordshire, and nearby areas. Mon–Sun 09:00–20:00.
AdBlue is water-based. When it spills, leaks, or sits in places it shouldn’t, it dries out and leaves a white, chalky residue.
That residue is AdBlue crystallisation.
A little crust round the filler cap does not always mean disaster.
The problem starts when crystals build up inside lines, the injector, or sensor areas.
Then you get warnings, poor dosing, and sometimes a countdown.
Quick question
Have you noticed any white crust near the AdBlue filler, under the van, or near the exhaust area?
If yes, this post will help you decide what to do next.
If you’re already seeing “start prevented” or a mileage countdown, don’t leave it.
The vehicle can stop you restarting when it hits zero.
What AdBlue crystallisation looks like
Most people describe it as chalk, salt, or dried sugar.
It can be powdery, crusty, or rock-hard depending on heat and how long it’s been there.
Around the filler neck
Usually caused by small spills during top-ups.
If it keeps returning, it can also hint at a loose cap seal or minor leak.
Under the vehicle
White streaks or crust near the tank area or lines can suggest a leak.
Leaks often start small and get worse after winter.
Near the exhaust/SCR area
This can point to dosing issues, injector misting, or crystallised deposits in the injector area.
That’s when faults become more likely.
Why crystallisation happens
AdBlue contains urea and deionised water.
When the water evaporates, the urea can form crystals.
Heat, airflow, and repeated small spills speed it up.
Spillage during top-ups
A quick pour, a cheap spout, or a rushed top-up leaves fluid on paint, plastic, and seals.
It dries and turns into crust.
Minor leaks
Small leaks from caps, seals, lines, or fittings can leave a trail.
The leak might not drip like oil. It can just leave white staining.
Heat and short journeys
Short runs can mean incomplete system cycles.
Combined with heat near the exhaust, any tiny deposit can bake into a hard crystal build-up.
Poor storage or contaminated fluid
Old containers, water ingress, or dirt in the neck can push the system towards blockages and sensor issues.
It’s not always the cause, but it adds risk.
If you want to top up without making a mess, use this guide:
how to top up AdBlue without spills
.
How crystallisation leads to AdBlue faults
Crystals do not just look messy.
They can block flow, upset sensor readings, and stop the SCR system working the way the ECU expects.
When that happens, you get warnings.
Injector restriction
If the injector tip or housing gets deposits, dosing can become weak or uneven.
The ECU sees poor NOx reduction and starts flagging an SCR problem.
Line blockage or pressure issues
Build-up in the line or fittings can affect pressure.
That’s when you see low-pressure or dosing-related faults.
Sensor contamination
Deposits and leaks can affect sensors and connectors.
Then the ECU gets bad readings and thinks the SCR system is not performing.
Repeat warnings after resets
Clearing codes without sorting the deposits often buys you a short break.
Then the warning comes back on the next few trips.
If you’re seeing fault codes, this page helps you decode them:
top AdBlue fault codes
.
Safe checks you can do (no tools)
You don’t need to pull anything apart to spot early signs.
You just need to look in the right places.
- Check the filler area for white crust and sticky residue
- Check under the vehicle for white streaks near the tank and lines
- Notice any strong ammonia-like smell near the rear of the vehicle
- Watch for repeat “top up” messages even after filling correctly
- If a countdown starts, note the exact wording and miles remaining
If you’ve hit a countdown stage, start here:
no-start countdown bypass
.
How to reduce crystallisation risk
You can’t control every design quirk, but you can cut the usual causes.
These steps are simple and make a difference.
Use a proper spout
Most crystallisation round the filler starts with spills.
A decent spout and slower pour helps.
Wipe the neck after filling
A quick wipe stops residue drying in the cap and seal area.
That’s where crust tends to build up first.
Store AdBlue properly
Keep it sealed, clean, and out of extreme heat.
If you want the full guide, we cover it in our post on AdBlue shelf life.
Cold weather can make small issues show up faster.
If winter is when your warnings start, read:
winter AdBlue problems
.
When you should book a mobile visit
If crystals keep returning, the warning comes back after clears, or a countdown has started,
you’ll save time by getting it checked properly.
The “don’t wait” signs
- A “start prevented” countdown has appeared
- You see heavy crust near the SCR/injector area
- You top up correctly and the warning still won’t clear
- The fault returns every few drives
- You have multiple AdBlue-related codes stored
If you want to understand your options from the main service page, start here:
AdBlue repair
.
If you need the mobile setup, see:
mobile service
.
